The Series 14 and 15 is a much heavier, longer-lasting machine for considerably less money. Initial investment is usually recovered in a remarkably short time and maintenance costs are minimal. It offers the innovative features and uncompromising quality in construction and workmanship that you can only get from a Schutte hammer mill.

The Series 14 and 15 features special ribbed grinding plates located at the front and rear of the machine to handle bark and other troublesome material with ease. Action against the plates cuts and disintegrates the wood fibers promoting faster and more effective screen grinding.

Schutte's properly sized vacuum fan system minimizes power consumption. We match CFM to the mill's screen area for optimum throughput capacity. Fan systems are available from 4,000 CFM up to 15,000 CFM. Separate motor driven fan systems provide for positive evacuation.

Extra rugged, all-welded-not riveted - steel construction increases wear life and make it impossible for blades to fly off for added safety. The housing is equipped with a replaceable liner and is designed to allow removal of both fan and liner without disturbing the blow pipe.

Heavy notched hammers are provided with the Series 14 and 15 for normal wood residue grinding. Fine, close grain, specially hardened steel retains sharpness and has the toughness needed to withstand wear Heavy, hardfaced strap hammers are recommended for such materials as bark. They are made from special steel and heat treated to retain sharpness in long, full service life.
